EAT LPS Linear Power Supply

What You Need to Know

The Power Supply Is Part of the Signal Path

European Audio Team believes your component’s power supply contributes directly to its sound—so the LPS Linear Power Supply is engineered without compromise. Full-bridge rectification with ultra-fast diodes feeds a huge 8,800µF filtration bank, regulated by fully discrete circuitry with no op-amps anywhere.

The results rival or beat battery power: ripple below 1 microvolt, voltage accuracy better than ±0.05%, and RFI eliminated from the mains before it ever reaches your phono preamp or turntable.

Two Power Supplies in One

The LPS is really two independent linear supplies in a single chassis: a 15V/2A output and an 18V/1.5A output. Power an EAT turntable and phono preamp at the same time—or any two compatible components. Three cables are included, covering EAT turntables and phono stages as well as most Pro-Ject turntables and Phono Box electronics.

Styled to Match Your System

The LPS cabinet comes in white or black, with three side panel options: Macassar ebony wood, gloss black wood, or no side panels for a slimmer, minimalist look. Whichever you choose, its low-profile chassis sits elegantly beneath or beside the components it powers.

Features & Specifications

Ultra-Fast Full-Bridge Rectification
With an 8,800µF filtration bank for massive, quiet reserves.

Discrete Regulation, No Op-Amps
TL431 voltage reference; ripple below 1 microvolt.

Dual Independent Outputs
15V/2A and 18V/1.5A—power two components at once.

Three Cables Included
Fits EAT and most Pro-Ject turntables and phono electronics.

Your Choice of Styling
White or black cabinet; Macassar, gloss black, or no side panels.

Specifications

•          Type: Dual-Output Linear Power Supply

•          Output 1: 15V DC / 2A (noise max 10µV)

•          Output 2: 18V DC / 1.5A (noise max 1µV)

•          Voltage Accuracy: Better than ±0.05%

•          Ripple: Less than 1µV

•          Filtration: 8,800µF Capacitor Bank; TL431 Voltage Reference

•          Compatibility: EAT Turntables and Phono Preamps; Most Pro-Ject Turntables and Phono Box Models

•          Included Cables: 15V 2.1mm, 15V 4-Pin XLR, 18V 2.5mm

•          Mains: 120V AC

•          Dimensions: 17.1“W x 2.4”H x 10.7"D

•          Weight: 10.8 lbs

•          Cabinet: White or Black; Side Panels: Macassar Ebony, Gloss Black, or None

Frequently Asked Questions

Which components can it power?
EAT turntables and phono stages (including the C-Sharp, C-Major, E-Flat, Forte, and E-Glo S), plus nearly all Pro-Ject turntables and Phono Box models. The three included cables cover the common connections—ask us about your specific components.

Can it power two components at once?
Yes—the LPS contains two truly independent supplies with separate outputs, so a turntable and phono preamp (or any two compatible components) can share one LPS.

What difference will I hear?
A phono signal is tiny, so power supply noise ends up in the music. Replacing a stock wall adapter with the LPS’s near-silent regulated power lowers the noise floor—revealing quieter backgrounds, finer detail, and more natural dynamics.
