Monitor Audio CP-IW260X In-Wall Speaker - Each
What You Need to Know
The Monitor Audio CP-IW260X is a serious theater speaker that happens to live inside your wall. This three-way, five-driver LCR design arrays dual 6.5-inch bass drivers and twin 4-inch midrange drivers symmetrically around a Gold Dome tweeter (B-M-T-M-B), delivering the output, dynamics, and pinpoint imaging of a substantial floorstander—with 150 watts of power handling and response from 50Hz to 30kHz. Use it behind an acoustically transparent screen or flanking a display for left, center, and right channels that genuinely match.
Unlike open-back in-walls, the CP-IW260X is built into its own sealed cast-polymer enclosure—rigid, acoustically damped, and consistent in any wall cavity, with no separate back-box to buy. An audiophile-grade crossover with low-loss inductors and polypropylene capacitors handles the three-way transition, and Monitor Audio's patented Tri-Grip fixing system installs faster than conventional clamps with three times the gripping area.
Features & Specifications
3-Way, 5-Driver LCR Array — Dual 6.5" bass and dual 4" mid drivers flank a Gold Dome tweeter for theater-grade output.
Sealed Cast-Polymer Enclosure — Consistent, predictable bass in any wall; no back-box required.
Audiophile Crossover — Low-loss inductors and polypropylene capacitors for a seamless three-way blend.
Tri-Grip Fixing System — Patented mounting with 3x the surface area of conventional clamps.
150W Power Handling — Reference-level dynamics for dedicated theaters and media rooms.
Specifications
- Type: 3-Way, 5-Driver Closed-Box In-Wall LCR Speaker (Controlled Performance Series)
- Drivers: 2 x 6.5" Bass; 2 x 4" Midrange; 1 x Gold Dome Tweeter (B-M-T-M-B)
- Frequency Response: 50Hz - 30kHz
- Sensitivity: 89dB (1W @ 1m)
- Nominal Impedance: 6 Ohms
- Power Handling: 150W RMS
- Enclosure: Sealed Cast-Polymer Cabinet (no back-box required)
- Mounting: Patented Tri-Grip Fixing System
- Cut-Out Dimensions: 34.65"H x 9.06"W (880 x 230mm)
- Mounting Depth: 3.78" (96mm)
- Grille: Paintable
- Finish: White / Paintable
- Sold By: Each
Why Audio Advisor?
- 40+ Years of Expertise – Helping music lovers build better systems since 1981.
- 60-Day Money-Back Guarantee – Hear it in your own system with confidence.
- Real Product Experts – Friendly advice before and after your purchase.
- Free Shipping – On qualifying orders over $49.
- Flexible Financing – Convenient payment options available.
- Compact three-way, five-driver in-wall/in-ceiling speaker
- Dual 4" C-CAM mid-range drivers with underhung voice coil
- 25 mm (1") C-CAM Gold Dome tweeter
- Portrait or landscape orientation
- Integrated back-box provides rear sound isolation resulting in ‘controlled performance’
- Cast Polymer enclosure provides a high degree of rigidity and acoustic damping properties
- High overall efficiency and maximum SPL for powerful home theatre installations
- High power handling
- Three-way design in a symmetrical ‘B-M-T-M-B’ configuration
- High-end crossover design – featuring low loss inductors and audiophile grade Polypropylene capacitors
- Patented Tri-Grip fixing system is easier to install than conventional clamping systems providing three times the surface area and improved sealing
- Trim-less, low profile magnetic grilles provide attractive, discreet visual aspect and easy installation and servicing
- Sensitivity (1W @ 1M): 89 dB
- Mounting Depth: 3.8"
- Power Handling (RMS): 150 Ws
- Nominal Impedance: 6 ohms
- Driver Size: 6.5"
- Cut-Out Width: 9.0"
- Cut-Out Height: 34.7"
