Monitor Audio SB 3 High Performance Passive Soundbar

Three True Channels. Built for Big Screens.

The Monitor Audio SB-3 is made for large TVs. It is more than 51 inches wide. That looks right under a 60-inch screen or bigger.

Inside are three real speakers. The left and right each get one 4-inch driver and one gold dome tweeter. The center gets two 4-inch drivers and a tweeter of its own. Voices are the hardest part of movie sound, so the center gets the most help.

The bar is passive. Your receiver powers it. There is no built-in amp to wear out, and no software making guesses for you. Better gear down the road means better sound from this same bar.

The cabinet is just 3.5 inches deep. Passive bass units add weight down low without a big box. Set it on the feet in the box, or hang it with the BSB bracket, sold on its own. Add a subwoofer and cross it over near 80Hz.

Key Features

Three Real Channels — Left, center, and right each get their own drivers.

Gold Dome Tweeters — One per channel. They reach all the way up to 30kHz.

Stronger Center Channel — Two 4-inch drivers just for voices.

Passive Bass Units — They add low-end weight from a cabinet only 3.5 inches deep.

Made for 60" TVs and Up — 51.5 inches wide, with feet for a shelf or a bracket for the wall.

Specifications

• Type: 3-Channel (LCR) Passive Soundbar
• Tweeters: 3 x 1" (25mm) C-CAM Gold Dome (one per channel)
• Bass/Mid Drivers: 4 x 4" (100mm) C-CAM Cone (one each L/R, two center)
• Bass Loading: Auxiliary Bass Reflex (ABR) — one per outer channel, two center
• Frequency Response: 80Hz - 30kHz (-3dB)
• Sensitivity (1W @ 1m): 84dB Left/Right; 87dB Center
• Nominal Impedance: 8 Ohms
• Power Handling (RMS): 40W Left/Right; 80W Center; 100W System
• Recommended Amplifier Power: 30 - 100W Per Channel
• Recommended Crossover to Subwoofer: 80 - 120Hz
• Maximum SPL: 104dBA (108.8dBA All Channels Driven)
• Dimensions: 5-11/16"H x 51-9/16"W x 3-1/2"D (145 x 1310 x 89mm)
• Weight: 20 lbs (9.1kg)
• Included: Integrated Silicone Feet (BSB Wall Bracket Sold Separately)
• Finish: Black
• Warranty: 5 Years
• Sold By: Each
