Ortofon OM 10 Stylus

Ortofon Stylus 10 Replacement Stylus for OM 10 Cartridges

What You Need to Know

The Factory Part That Restores Your OM 10 Completely

The Stylus 10 is Ortofon’s own replacement stylus for one of the most widely fitted cartridges in hi-fi — the OM 10 and its many relatives, from the Super OM 10 and OMP 10 to the Concorde 10 and TM 10H.

It is the genuine part, built to the same tolerances as the assembly your cartridge shipped with, so replacing it restores the performance you bought rather than approximating it.

An Elliptical Diamond That Tracks at a Lighter Touch

The 10 uses an elliptical diamond with an 8/18 µm tip radius, and it does its work at a recommended 1.5 g rather than the 1.75 g the 3E and 5E ask for. Less downward force in the groove, same tracking ability.

What you hear is a cartridge that stays composed where records get demanding — dense orchestral passages, massed vocals, the last track on a side — with the treble clarity an elliptical profile is known for.

Step Up Without Buying a New Cartridge

The OM family shares one body and one stylus mount, so yours already accepts the Stylus 20, 30, and 40 alongside the 10.

The Stylus 20 moves to a nude elliptical diamond with lower tip mass. The Stylus 30 steps up again to a nude Fine Line profile with an 8/40 µm radius that reads deeper into the groove. The Stylus 40 tops the range. All of them fit the same body in the same two minutes.

Do You Need a New Stylus?

Three things tell you it is time:

•       Damage. A bent cantilever, a chipped or missing diamond, or debris you cannot brush away means replace it now — a damaged stylus can permanently damage your record grooves.

•       Hours of play. Ortofon rates its styli for up to 1,000 hours of play with proper care, and closer to 500 hours under DJ use with back-cuing or scratching. A worn diamond stops tracking cleanly long before it looks worn to the naked eye.

•       Age. After roughly five years the elastomer suspension — the small damping ring that holds the cantilever in place — dries out and stiffens. The stylus still plays, but it no longer tracks or sounds the way it did new. Time for a fresh one.

Fitment & Installation

The Stylus 10 is the recommended stylus for the Ortofon Super OM 10, OM 10, OMP 10, OMB 10, OMT 10, LM 10, Concorde 10, Concorde EC 10, Concorde STD, TM 10H, LMB 12, SMB 12, and LMA 12. It is not the right part for the 2M series, Concorde MkII, VNL, or Ortofon’s moving coil cartridges — those use their own styli or are not user-replaceable.

Installation takes about two minutes. With the turntable switched off, hold the cartridge body steady, grip the stylus assembly from both sides, and pull it straight off the front; then press the new one on until it seats. No tools, no alignment, no re-setting the tonearm. Just confirm your tracking force sits in the 1.25–1.75 g range, and allow up to 20 hours of playing time for the new suspension to settle in. If you would rather step up while you are in there, the Stylus 20, 30, and 40 all fit the same body the same way.

Features & Specifications

Genuine Ortofon Replacement Stylus
Factory-original parts and tolerances bring your cartridge back to as-new performance.

Elliptical Diamond, 8/18 µm Tip Radius
Follows groove modulations closely for clean vocals and composed, detailed treble.

Light 1.5 g Tracking Force
Does its tracking with less downward pressure in the groove than entry-level styli require.

Fits the Whole OM Family
One of the most widely fitted stylus assemblies in hi-fi, and fully interchangeable with the Stylus 20, 30, and 40.

Specifications

•       Fits: Ortofon Super OM 10, OM 10, OMP 10, OMB 10, OMT 10, LM 10, Concorde 10, Concorde EC 10, Concorde STD, TM 10H, LMB 12, SMB 12, LMA 12

•       Stylus Profile: Elliptical, tip radius r/R 8/18 µm

•       Cantilever: Aluminum

•       Recommended Tracking Force: 1.5 g (range 1.25–1.75 g)

•       Expected Stylus Life: Up to 1,000 hours with proper care

•       Replacement Type: User-replaceable stylus assembly

Frequently Asked Questions

Will this fit my cartridge?
The Stylus 10 is the recommended replacement for the Super OM 10, OM 10, OMP 10, OMB 10, OMT 10, LM 10, Concorde 10, Concorde EC 10, Concorde STD, TM 10H, LMB 12, SMB 12, and LMA 12. It will not fit the 2M series, Concorde MkII, VNL, or Ortofon’s moving coil cartridges.

How long will it last?
Ortofon rates its styli for up to 1,000 hours of play with proper care — roughly 500 hours if you are back-cuing or scratching. Keep the calendar in mind too: after about five years the elastomer suspension dries out and stiffens, and performance falls off even when the diamond still has hours in it.

Can I upgrade to a better stylus?
Yes. Your cartridge body accepts the Stylus 20, 30, and 40 as well — the 20 brings a nude elliptical diamond with less mass at the tip, the 30 a nude Fine Line profile that resolves more groove detail, and the 40 sits at the top of the range. Each one installs exactly like the 10, so the upgrade costs you two minutes and no turntable setup.
